This is the start page of the ontology editor. You get here after you have logged in and selected the ontology editor from the set of available services. Clicking on the "Start ontology editor" link takes the user to the table of contents of the ontology library.

We start our ontology editing session by going to the library so that we can load the ontology that we're going to edit. We will make an edit to an ontology called Documents-2 and will then show some of the other features provided by the ontology editor. The Documents-2 ontology contains definitions of terms that might be useful in describing documents. This ontology might be useful, for example, in the definition of the database schema for a bibliographic database.

Stanford KSL Ontology Editor

Welcome to the Stanford KSL Ontology Editor

Start ontology editor

The Ontology Editor is a tool that supports distributed, collaborative editing, browsing and creation of Ontolingua ontologies.

If you are a new user, check out the guided tour.

Features
Frequently Asked Questions
Important release info
Known bugs
New features

Browser help

Help is available on all pages by means of the "?" (help) button.

Please note the meanings of the following icons:

: Selecting Home icon will return you to the KSL network services home page where you can start other services or alter characteristics of your current session. The other icons are all menu bar commands. Use the Help ("?") button on the menu bars on which these icons appear to find out what they mean. Menu bar help
: is the Edit icon. Selecting it will allow you to edit the entry next to the icon.
: is the Add item icon. It allows you to add in an object that is already known to the system. For example you would use the button to add a slot to a class. Creation of new slots must be done by pushing on the appropriate Create button.
: is the Insert Found Word tag. This option appears whenever possibilities are found by the numerous Find commands. Selecting this tag allows you to take the object immediately following it and insert it at the relevant place in the typein box that is prompting you. Extensive help is provided whenever you encounter the Find command. Click here for a worked example
...: Ellipses indicate that there are more possibilities resulting from executing a Find command or there are more slot or facet values available than are shown. Selecting the "..." will show more options or values. Selecting Find All will show all possibilities.
: indicates in the class browser that a class is "open" and then all of its direct subclasses (and instances if selected by user preference) are visible.
: indicates in the class browser that a class is "closed" and that display of the class's subclasses (and instances if selected by user preference) has been suppressed.
: tells the class browser to focus in on the class in front of the icon.
: is a button that will take you to the place that defined the value or object following the icon.
